The equipment includes 1 zero voltmeter, 1 circuit breaker, 3 signal lamps and terminal bolts.?With MV 1903 it is an easy matter to synchronize synchronous machines to networks.
General Data | MV1903-235 | MV1903-405 |
Zero Voltmeter | 2 x 140 V | 2 x 220 V |
Circuit Breaker | 16 A 500 V | 16 A 500 V |
Synch. Lamps | 130 V with resistor | 220 V with resistor |
Supply Voltage | 220-240 / 127-140 V? 50-60 Hz | 380-415 / 220-240 V? 50-60 Hz |
Dimensions | 315 x 240 x 90 mm | |
Weight | 3 kg | |
Other voltages can be supplied on request.
