MV2658 is an indispensable equipment in the electrical machines laboratory as it can be used in several different types of applications. It can be used as a DC-Machine Drive in the range up to 1.2kW, a Generator Field Controller (VAr controller), or a Machine Brake Controller suitable with Terco equipment in the range up to 3.3kW (see section 3 applications).
- PWM (16kHz) Based Excitation Voltage 0-260VDC.
- Selectable Current Limit Levels (front panel switch):?1.7ADC, 2.5ADC, 3.5ADC, 5.0ADC, 7.5ADC
- Fixed Excitation Output 200VDC (for DC Drive application).
- PWM Controlled Excitation on the front panel control?(0-100% Duty Cycle) or from the control input?(fully isolated, 0-10VDC = 0-100% Duty Cycle).
The control input can be used for instance in PC based control together with Terco DAQ software. (Optional analog output interface unit necessary).
- Control Methods selectable between PWM Controlled Excitation Voltage Feedback and External Analog Voltage Feedback.
- Power Supply 220-240VAC, 50/60Hz
- Dimensions: 255 x 195 x 330mm
- Weight: 8kg (approximatly)
