Tachometer

Beskrivning

To measure the rpm of a motor, the tachometer is connected to the motor shaft. The tachometer shows an analogue signal output in form of voltage which is in proportion to the rpm of the rotating shaft. It works like a DC generator. The measuring instrument has a scale of 0-2500 rpm.

Voltage output DC 0-20 V, may be used for voltage feedback to the DC or AC – Drive.

General data

Output:?

20 V DC at 2500 rpm

Dimensions:

210 x 160 x 150 mm

Weight:

3 kg
